CYPECAD. Reliable structures, very precise drawings



StruBIM Suite

Engineering software suite for buildings which calculates structural elements by carrying out the analysis, design, check, as well as providing the technical drawings for the structural project, (Record Engineer) of the elements that have been defined. The applications that work with the 3D model of the building are integrated in the Open BIM workflow via the BIMserver.center platform.



CYPECAD. Reliable structures, very precise drawings



MEP and CYPETHERM programs

Group of CYPE programs developed to carry out the thermal and energy analysis of buildings, and design their lighting, sound and fire extinguishing installations. The applications that work with the 3D model of the building are integrated in the Open BIM workflow via the BIMserver.center platform.





CYPECAD. Reliable structures, very precise drawings

CYPECAD
Reliable structures, very precise drawings

Program that carries out the analysis and design of reinforced concrete and steel structures, subject to horizontal and vertical loads, for homes, buildings and civil work projects. Its use guarantees maximum analysis reliability and optimum drawing design.

The geometry of the structure can be introduced automatically. The user can personalise the design and edit the elements that have been introduced, with the on-screen support provided: numerous help options and error and warning texts. Provides very complete and precise construction drawings of the structure. CYPECAD is adapted to the latest national and international construction codes.

CYPE 3D. Power, efficiency and productivity for steel and wooden structures

CYPE 3D
Power, efficiency and productivity for steel, timber, aluminium and
concrete structures

It is an agile and efficient program brought about to carry out the design of three dimensional structures composed of steel and timber bars, and their foundations, which includes pad footings, pile caps and strap and tie beams. Additionally, these can be redesigned and so obtain their maximum optimisation.

It has been adapted to national and international steel, timber, aluminium and concrete construction codes. The program carries out the analysis, design and check of the fire resistance of timber sections. Performs a seismic analysis of the structure (Modal Spectral Analysis) according to national and international codes. Second order effects (P-delta) are considered with wind and seismic loads.

Punching shear verification

Punching shear verification

Punching shear verification is a program that checks the Failure Limit State of concrete for punching shear in flat and waffle slabs exposed to concentrated loads from rectangular or circular supports.

The program can check slabs with or without transverse punching shear reinforcement, takes into account the presence of openings or lightweight zones in the slab, and the position of the supports (internal, edge or corner).



Continuous beams


Continuous beams

Continuous beams is a program which has been conceived to analyse, design and check continuous beam alignments of frames made out of concrete, and rolled, welded and cold-formed steel (with various floor slab arrangements) based on the introduced geometry of the alignment and loadcase of the acting forces. The program offers detailed ultimate limit state check reports and detailed drawings containing the corresponding reinforcement detailing.



CYPE. Simple and trustworthy programs for soil retentionSoil retention elements
Simple and trustworthy programs for soil retention

Reinforced concrete cantilever walls. Program designed for the design and check of reinforced concrete cantilever soil retaining walls. Provides the automatic optimum design of the geometry, calculates the section reinforcement and carries out the geometric and reinforcement design of the foundation.

Embedded retaining walls. This has been developed for the design and check of generic embedded retaining walls composed of any material; reinforced concrete, reinforced concrete secant pile walls, mini pile screen and steel sheet piles. The program designs the reinforcement in the case of reinforced concrete walls. An assistant is available to help introduce the data for the most common cases of several basements levels in buildings. A simple assistant is also available for buildings with one or two basement levels.

Box culverts. The solution to lower passagesBox culverts
The solution to lower passages

Box Culverts is a program developed for the design and analysis of reinforced concrete box culverts used for underpasses, subways, and drainage works. They can be rectangular, trapezoidal or any type of polygon designed on screen, as well as being single cell or multiple cell elements.

The program can also design culverts made up of various aligned prestressed elements by defining the joints or those to be executed on site.

Arquimedes. The versatile program for Project Management
Arquimedes
The versatile program for Project Management

The most complete tool for Project Management: bills of quantities, project certifications and specifications.

Automatic quantity imports and certifications using DXF and DWG templates. Gantt charts and data export to Excel.



Arquimedes. The versatile program for Project ManagementCYPECAD MEP
Mechanical, electrical and plumbing

CYPECAD MEP is a program for the design of the envelope, distribution and services of the building using an integrated 3D model with the various elements of the building. The English version of CYPECAD MEP designs air conditioning installations and carries out dynamic fire simulations in buildings.

CYPECAD MEP contemplates the following types of buildings: Household (detached, terraced, multi-family) Commercial, Administrative, Residential, Car park, Public attendance, Teaching, Hospital and Industrial.
